Data provisioning

Connection details

In the Domain name field, type the address of the domain used for the Azure tenant, such as example.com. The value is used when provisioning new users.
In the API Version field specify the Microsoft Graph API version. By default, it is set to version 1.0 and the value should usually not be changed.
Optionally, specify the Tenant ID. Type or paste the Directory ID of the directory for the Omada Identity application you have created on Microsoft Entra ID. You can find the Directory ID by going to the Properties section for the relevant directory on the Microsoft Azure Portal.If value is not specified, the connector will use the value specified under Connection details. You should only specify a value here if you have not used the standard Microsoft Entra ID collector to load information.
Optionally, specify the Application ID. Type the ID of the Omada Identity Azure application that you must create in the Microsoft Azure Portal. Find the Application ID under Settings in the Microsoft Azure Portal. If the value is not specified, the connector will use the value specified under Connection details. You should only specify a value here if you have not used the standard Microsoft Entra ID collector to load information.
Optionally, specify the Client secret. Type or paste the value of a key that you have created in the Microsoft Azure Portal. If value is not specified, the connector will use the value specified under Connection details. You should only specify a value here if you have not used the standard Microsoft Entra ID collector to load information.

Optionally, configure the Headers field. You can provide a JSON document specifying custom headers, for example:

{"Request": {"Accept": " text/html","contenttype":
"application/json","SomeCustomHeaderWithValue":
"custom value", "SomeCustomHeaderWithoutValue":
null}}

Optionally, enable the Test connection setting to make sure that the details that you entered are correct.

Data model

The data model for Microsoft Entra ID Connectivity supports the following objects:

MSEntraIDUser

The MSEntraIDUser object is used to create, update, and delete users in Microsoft Entra ID. It has the following properties (the parameters listed in the table above are not all the available parameters but only the commonly used ones, you can extend the object with additional parameters if required):

Parameter	Type	Description
Object Id	Expression	`string.Format("{0}@{1}", ROPE_AccountName, ConnectorConfiguration.GetValue("DomainName")`
Object type	Constant	users
Operation	-	`Operation == "DeleteIfExists" ? "Delete" : Operation`
userPrincipalName*	Expression	`Operation=="Create" ? string.Format("{0}@{1}", ROPE_AccountName, ConnectorConfiguration.GetValue("DomainName")) : null`
accountEnabled**	Expression	`Operation == "DeleteIfExists" \|\| Operation == "Delete" ? null : ROPE_Disabled ? "false" : "true"`
displayName**	Expression	`Operation == "DeleteIfExists" \|\| Operation == "Delete" ? null : ROPE_Identity`
givenName	Map	ROPE_ATTR_FIRSTNAME
surname	Map	ROPE_ATTR_LASTNAME
mailNickname**	Expression	`Operation=="Create" ? ROPE_AccountName : null`
mail	Map	ROPE_ATTR_EMAIL
passwordProfile.password**	Expression	`Operation=="Create" ? ROPE_ATTR_INITIALPASSWORD : null`
passwordProfile.forceChangePasswordNextSignIn	Expression	`Operation=="Create" ? "true" : null`
businessPhones	Map	ROPE_ATTR_CELLPHONE
`manager@odata\.bind`	Expression	`Operation == "Create" && ROPE_ATTR_MANAGER[0] != ROPE_AccountName ? string.Format("https://graph.microsoft.com/v1.0/users/{0}@{1}", ROPE_ATTR_MANAGER[0], ConnectorConfiguration.GetValue("DomainName")) : Operation == "Update" && ROPE_Disabled == false ? string.Format("https://graph.microsoft.com/v1.0/users/{0}@{1}", ROPE_ATTR_MANAGER[0], ConnectorConfiguration.GetValue("DomainName")) : null`
usageLocation	Constant	Country code (examples: US, ES, GB)
